Specification:
Height adjustable range: 300 mm to 1040 mm
AC input: 110VAC-240VAC, 50/60Hz, 382VA
Power supply: Class I power supply
Applied part: Applied part type ‘B’
Battery specification: Lead acid battery/ “non-spillable” Input 30V – Output 24V
Supplier reference: TiMotion (TBB2-4307-001)
Battery model: TiMotion TBB2 1.2A
Fuses: 5Amp fuses (External to the device, part of the mains supply system)
Duty cycle: 10% maximum
Maximum working load: 500 lbs (227 kg)
Sound emission: LAeq 56dB at maximum working load
Length: 75.25” (1911 mm) or 71” (1800 mm)
Height: 76.25” (1937 mm)
Depth: 40” (990 mm) – Stretcher and guard deployed
Weight of product: 216 lbs (98 kg)
Materials: Mild Steel, Stainless Steel, Polyethylene
Operating ambient temperature range: 10°C to 40°C / 50°F to 104°F
Operating relative humidity range: 10 – 80% not condensed at 20°C / 68°F
Operating atmospheric pressure: 50kPa to 106kPa
IP Class: IPX4
Transport & storage conditions: 10°C to 40°C / 50°F to 104°F 10 – 80% not condensed at 20°C / 68°F
